顏色

Color

淺黃色

目視

Visual

--

厚度(mm)

Thickness

1～4

PEACOCK厚度規

PEACOCK THICKNESS METER

ASTM D374

密度(g/cc)

Density

2.15(±0.2)

BS-H電子天平

BS-H ELECTRONIC BALANCE

ASTM D792

硬度(Shore A)

Hardness

10～15

LX-C型微孔材料硬度計

LX-C CELLULAR MATERIAL DUROMETER

ASTM D2240

導熱係數(W/m.K)

Thermal Conductivity

≥1.2

Long-Win9389導熱係數測試儀

Long-Win9389 THERMAL CONDUCTIVITY TESTER

ASTM D5470

熱阻(℃in²/W)(@20psi&1mm)

Thermal Resistance

≤1.5

DRL-Ⅲ導熱係數測試儀

DRL-Ⅲ THERMAL CONDUCTIVITY TESTER

ASTM D5470

擊穿電壓(KV)(@1mm)

Breakdown Voltage

≥10

MS2676A耐壓測試儀

MS2676A WITHSTAND VOLTAGE TESTER

ASTM D149

體積電阻率(Ω.cm)

Volume Resistivity

≥10¹⁰

ZC-36高絕緣電阻測量儀

ZC-36 HIGH DIELECTRIC RESISTANCE TESTER

ASTM D257

壓縮比(%)(@7.57psi)

Compression Ratio

≥20

壓縮力測試儀

COMPRESSINVE FORCE TESTER

ASTM D 695

撕裂強度

(N/mm)

≥2.5

拉力試驗機

ASTM D 624

拉伸強度 (Mpa)

Tensile Strength

≥0.4

拉力試驗機

TENSION TESTER

ASTM D 412

延伸率(%)

 Elongation

≥150

防火性能

UL Certify

UL94-V0

阻燃測試儀

FLAME RATING TESTER

UL 94

使用溫度 (℃)

Operating Temperature

-50~180

可程式冷熱衝擊箱

PROGRAMMABLE THERMAL SHOCK TESTER

--
